AC/DC Charger/Adapter

CT5702B Datasheet

The CT5702B is a synchronous rectifier for Flyback converters. It integrates a 40V power MOSFET, that can replace Schottky diode for high efficiency

The CT5702B have multi-protection functions which largely enhance the safety and reliability of the system.

The CT5702B is available in SOP-8 package.


  • Integrated 19mΩ 40V Trench MOSFET
  • Supports DCM and Quasi-Resonant Flyback
  • Precise Synchronous Rectifier VDS detection
  • MOSFET Fast Shutdown Ability within 20nS
  • Supports Low-side Rectification
  • VDD UVLO Protection
